ProLine element

CS 1018

with one burner

sale price$3,800.00

GST inclusive



Product details

  • Professional design - 288 mm wide stainless steel trough
  • Broad performance spectrum - dual wok with up to 5.400 kW kW of power
  • Simple controls -single-handed operation via rotary dial control
  • Extremely safe -
    GasStop function
  • Particularly high-quality - enamelled cast-iron pot rests
  • Manufactured with great care by
  • Safety Information

Product data sheet

Heating type Gas
ProLine
Elegant glass ceramic surface
Stainless steel trough
Cast iron pot rests (matt black enamelled)
Miele logo embossed in stainless steel
Number of cooking zones 1
Dual wok burner in kW 5.40
Position Centred
Type Dual wok burner
Max. rating in W 5400
Operation via sensor controls Knob
Operation via knobs
Electronic ignition with single-hand operation
Easy to clean ceramic glass
GasStop
GasStop & ReStart
Dimensions (W x D) in mm 288 x 73 x 520
Dimensions in mm (width) 288
Dimensions in mm (height) 73
Dimensions in mm (depth) 520
Cut-out dimensions (W x D) with surface-mounted installation in mm 272 mm x 500 mm
Casing height incl. connection box in mm 106
Cutout dimensions in mm (width) with surface-mounted installation 272 mm
Cutout dimensions in mm (depth) with surface-mounted installation 500 mm
Weight in kg 8
Total rated load in kW 5.400
Position of gas connection Hinten links
Voltage in V 220-240
Frequency in Hz 50-60
Length of supply lead in m 1.4
Mains cable
EAN 4002514448930

What's included

Mains cable

User convenience

CombiSet appliances leave nothing to be desired
CombiSet – combination

Variety is the programme: The CombiSet programme offers professional appliances for every type of cooking.


Design in detail
Rotary dial controls

Matching convenience: metal rotary dial controls* complement the design style of the ProLine elements.


Ergonomics in detail
Inclined control panel

Perfect looks: The ergonomically arranged control panel simplifies operation.


Safety

Automatic reignition for extra safety
GasStop & ReStart

Safe cooking: Automatic re-ignition for flame failure Should this prove unsuccessful, the gas supply is turned off immediately.


Design

The perfect combination
Stainless-steel frame

Uniform frame design: no matter which ProLine appliances are installed, they always match each other perfectly.


Downloads

Operating instructions/Installation instructions
PDF
Downloads
Product Fact Sheet
PDF
Downloads
rvt
ZIP
Downloads
fbx
ZIP
Downloads
rfa
ZIP
Downloads
ifc
ZIP
Downloads
dwg
ZIP
Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/images/2000007/200000718/20000071809.png
Descriptions
CS 1018 (Installation drawing)
1. Spring clamps, 2. Front, 3. Building-in depth, 4. Mains connection box with mains connection cable, L = 1400 mm, 5. Gas connection R 1/2 - ISO 7-1 (DIN 10226)
