Slimline cooker hood

DAS 4630 Obsidian black

with intuitive SmartControl controls
Colour:Obsidian black
sale price$3,800.00

GST inclusive



Product details

  • Elegant design – obsidian black control panel, 60 cm wide
  • Unique user convenience –
    Con@ctivity
  • LED strip for uniform lighting
  • Efficient filtration-
    10-ply stainless-steel grease filter
  • Recirculation mode –
    Active AirClean or Longlife AirClean filter
  • Manufactured with great care by
  • Safety Information

Product data sheet

Slimline cooker hood
Type of air guide Can be retrofitted
Recirculation conversion kit (order separately) DUU 151,DUU 150
Active charcoal filter (order separately) [ "DKFS 31-R", "DKFS 31-P" ]
Colour Obsidian black
Miele@home
Automatic function Con@ctivity
Electronic controls
Touch-on-glass controls
Controls SmartControl
Booster levels 1
Run-on time 5/15 min.
Grease filter saturation indicator
Active charcoal filter saturation indicator
Easy-to-clean canopy interior – CleanCover
Number of dishwasher-safe stainless steel grease filters (10-ply) 1
Number x W 1 x 3 W
Light intensity in Lx 330 lx
Colour temperature in K 3500 Kelvin
Dimmer function
Fan power (m³/h) 1145
Dual-action blower
Air throughput in Level 1 (m³/h) according to EN 61591 345
Air throughput in Level 2 (m³/h) according to EN 61591 500
Air throughput in Level 3 (m³/h) according to EN 61591 655
Air throughput in Booster level 1 (m³/h) according to EN 61591 925
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 50
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 59
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 65
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3 73
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 36
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 45
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 51
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13 59
Air throughput in Level 1 (m³/h) according to EN 61591 345
Air throughput in Level 2 (m³/h) according to EN 61591 495
Air throughput in Level 3 (m³/h) according to EN 61591 655
Air throughput in Booster level 1 (m³/h) according to EN 61591 865
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 58
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 68
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 74
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3 81
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 44
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 54
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 60
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13 67
Safety shut-off
Single-ply safety glass (ESG)
Canopy width in in. (mm) 596
Canopy height in in. (mm) 36
Depth of hood canopy in in. (mm) 273
Net weight in kg 14
Length of supply lead in m 1.8
Standard plug fitted
Total rated load in kW 0.293
Voltage in V 230
Fuse rating in A 10
Frequency in Hz 50
Number of phases 1
Extraction ducting connection at top
Diameter of extraction ducting connection in mm 150
Non-return flap
EAN 4002516496144

What's included

Non-return flap
Automatic operation for intelligent fan control
Con@ctivity

Innovative convenience: the cooker hood reacts automatically to settings on the hob.

Easy to use and effective against grease
Stainless steel grease filters (10-layer)

Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.

Convenience and safety in detail
Miele CleanCover

Protection and easy cleaning: the sealed, smooth surface prevents contact with cables and the motor.

Elegant touch controls
SmartControl

High-quality and functional: enjoy convenient touch controls with a dimmer function.

Features

Easy to use and effective against grease
Stainless steel grease filters (10-layer)

Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.

Convenience and safety in detail
Miele CleanCover

Protection and easy cleaning: the sealed, smooth surface prevents contact with cables and the motor.

User convenience

Automatic operation for intelligent fan control
Con@ctivity

Innovative convenience: the cooker hood reacts automatically to settings on the hob.

Automatic fan run-on
Run-on function

Odour-free room air: after cooking, the fan can be set to switch off automatically after a 5 or 15 minute run-on period.

Countdown time conveniently in view
Filter indicator

Easy filter replacement: a red light lets you know when the grease and/or active charcoal filter is saturated.

Elegant touch controls
SmartControl

High-quality and functional: enjoy convenient touch controls with a dimmer function.

Safety

Always on the safe side
Safety switch-off

Sensible, even in case of operating errors: the cooker hood switches off automatically after 10 hours.

Matching products and accessories

Recirculation conversion kit for DA 3xxx/2xxx and DAS 2xxx, 4xxx and 8xxx
DUU 151

Recirculation conversion kit for DA 3xxx/2xxx and DAS 2xxx, 4xxx and 8xxx

to convert slimline/integrated cooker hoods from extraction to recirculation.

$305.00
Wall box
DMK 150-1

Wall box

for extraction.

$755.00
Condensation trap
DKS 150

Condensation trap

Prevents condensation from re-entering the cooker hood canopy.

$344.00
Roof vent
DDF 125

Roof vent

for extraction.

$970.00
Aluminium vent hose
DAS 150

Aluminium vent hose

flexible vent duct.

$305.00
Silencer
DASD 150

Silencer

for reducing air and motor noises.

$284.00
Silencer connection
DASDV 150

Silencer connection

between silencer and connector.

$74.00
Reducing collar
DRS 15-12

Reducing collar

for reducing the exhaust air vent cross-section.

$49.00
Multi-purpose microfibre cloth, qty 1
GP MI X 0011 W

Multi-purpose microfibre cloth, qty 1

For best cleaning results and safe use.

$25.00
MicroCloth kit, 3 pieces
GP MI S 0031 W

MicroCloth kit, 3 pieces

For best cleaning results and safe use.

$50.00

Downloads

Operating instructions/Installation instructions
PDF
Downloads
Mounting plan
PDF
Downloads
rvt
ZIP
Downloads
fbx
ZIP
Downloads
rfa
ZIP
Downloads
ifc
ZIP
Downloads
dwg
ZIP
Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/images/2000018/200001840/20000184041.png
Descriptions
DAS4630, DAS4631 - Skizze, PAC, CN
① Exhaust air, for dimensions for cabinet height and cutouts, mounted accessories must be taken into account., ② Exhaust air, recirculation with conversion kit DUU 150., , *In this installation situation, the screen is flush with the front edge of the cabinet. If the cooker hood is positioned further forward or back (e.g. when using a front panel), the dimensions must be adjusted accordingly.
