SmartLine element
CSDA 7001 FL
as downdraft extractor for extraction or recirculation operation
Product details
- Intuitive quick selection via number sequences –Smart SelectLoading...
- Elegant design – for flush or raised installation
- Seamlessly integrates with anySmartLine elementLoading...
- Efficient filtration-10-ply stainless-steel grease filterLoading...
- Energy-efficient and quiet - powerfulECO motorLoading...
- Manufactured with great care by
- Safety Information
Downdraft extractor
Type of air guide Can be retrofitted
Recirculation conversion kit (order separately) DUU 1000-2
Flat ducting components (order separately) DFK- xxxx
Flush
Frameless – surface-mounted
Operation via sensor controls Smart Select
Digital power level display
Display colour Yellow
Run-on time 5 min.
Energy efficiency class (A+++ to D) A++
Annual energy consumption in kWh/year 25.3
Fluid dynamic efficiency class A
Lighting efficiency class NA
Grease filtering efficiency class B
ECO motor
Loading...
Easy to clean ceramic glass
Easy-to-clean canopy interior – CleanCover
Loading...
Number of dishwasher safe stainless-steel grease filters (10-ply) 1
Air throughput in Level 1 (m³/h) according to EN 61591 150
Air throughput in Level 2 (m³/h) according to EN 61591 290
Air throughput in Level 3 (m³/h) according to EN 61591 440
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 58
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 29
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 43
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 51
Sound power in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13 55
Air throughput in Level 1 (m³/h) according to EN 61591 100
Air throughput in Level 2 (m³/h) according to EN 61591 235
Air throughput in Level 3 (m³/h) according to EN 61591 380
Air throughput in Booster level (m³/h) according to EN 61591 460
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 49
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 63
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 73
Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3 78
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 49
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 58
Sound power in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13 63
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 34
Safety switch-off
FlameGuard
Dimensions (W x D) in mm 222<NBSP/>x<NBSP/>89
Dimensions in mm (width) 120
Dimensions in mm (height) 168
Dimensions in mm (depth) 520
Casing height incl. connection box in mm 168
Cutout dimensions in mm (width) with surface-mounted installation 100 mm
Cutout dimensions in mm (depth) with surface-mounted installation 500 mm
Inner cut-out dimensions in mm (width) with flush installation 100
Inner cut-out dimensions in mm (depth) with flush installation 500
Outer cut-out dimensions in mm (width) with flush installation 124
Outer cut-out dimensions in mm (depth) with flush installation 524
Weight in kg 11
Total rated load in kW 0.170
Voltage in V 230
Fuse rating in A 10
Number of phases 1
Length of supply lead in m 2
Plinth fan with vent connection
Extraction connection at rear and side
Dimensions of the exhaust ducting connector in mm 222
Dimensions of the exhaust ducting connector in mm 89
Ducting system to the plinth fan
Loading...
Ducting system to the plinth fan
Loading...
EAN 4002516304906
Ducting system to the plinth fan
Ducting system to the plinth fan
Easy to use thanks to SmartSelect
SmartSelect
Quick and intuitive: power levels and times can be selected separately for each cooking zone.
The heart of every cooker hood
ECO motor
Powerful and quiet: The DC motor saves up to 70% energy compared with conventional fans.
Easy to use thanks to SmartSelect
SmartSelect
Quick and intuitive: power levels and times can be selected separately for each cooking zone.
Greater safety when combined with gas
FlameGuard
Completely safe: thanks to the FlameGuard, the gas flame cannot be drawn into the countertop extractor.
Matching products and accessories
Downloads
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!
Descriptions
CSDA 7001 - flush (Installation drawing)
1) front, 2) Fan (in the plinth lying on the floor), 3) Stepped cut-out, 4) 12 mm wooden panel (not supplied as standard), 5) Air duct, 6) E-box
Descriptions
CSDA 7001 - supported installation (Skizze)
1) front, 2) Fan (in the plinth lying on the floor), 3) Air duct, 4) E-Box,
